Industrial Wireless Serial Device Server Series
SW550xC User Manual V 1.0
78
Combination 1: AW5500/AW5500C(A) + AW5500/AW5500C(B):
Overview of the settings that will be applied automatically:
AW5500/AW5500C(A)
Table 5.5
Operation Mode
WDS Bridge
Basic Settings
WDS Mode
Root AP
SSID
aabbccWDS*
SSID Broadcast
Disabled
Wireless Mode
802.11a/n
Click-2-Go Mode
Enabled
WDS Settings
Authentication
WPA2-PSK
Encryption
AES
Passphrase
aabbccWDSxxxx**
WDS MAC
-
AW5500/AW5500C(B)
Table 5.6
Operation Mode
WDS Bridge
Basic Settings
WDS Mode
Station
SSID
aabbccWDS*
SSID Broadcast
-
Wireless Mode
802.11a/n
WDS Settings
Authentication
WPA2-PSK
Encryption
AES
Passphrase
aabbccWDSxxxx**
WDS MAC
MAC address of AW5500(A)
* the aabbcc part will consist the last three bytes of the MAC address of the A device.
** the xxxx part will be generated by random.
