1. Introduction
AirLive SNMP-GSH2004L User’s Manual 3
LED Table
LED Color/Status Description
Power Green Power on
10/100/1000Ethernet TP Port 1 to 24 LED
Green On Link Up
Link/ ACT
Green Blinking Data activating
Green On Link 1000Mbps
SPD
Yellow On Link 10/100Mbps
1000SX/LX Gigabit Fiber Port 21,22,23,24 LED
Green On Link Up
Link/ ACT
Green Blinking Data activating
Green On Link 1000Mbps
SPD
Yellow On Link 100Mbps
1.4 Installation Steps
This section lists the installation procedures in steps. Each step’s instruction is thoroughly
explained in the subsequent sections of following chapter.
Step1. Connect your PC to the switch.
Step2. Set your PC's IP address to 192.168.2.50.
Step3. Open your web browser and enter "192.168.2.1" to get into the switch's web
management.
Step4. Enter "admin" for username and "airlive" for password.
Step5. If you want to install the switch on the 19" rack, please install the mounting kit.
Step6. Please see the following chapters for further configurations.
