SECTION 6 - JLG CONTROL SYSTEM
3121290 – JLG Lift – 6-35
3377 HEAD TAIL LIGHT - OPEN CIRCUIT
3378 HEAD TAIL LIGHT - SHORT TO BATTERY
3379 HOUR METER - SHORT TO GROUND
3382 PLATFORM LEVEL UP VALVE - SHORT TO GROUND
3383 PLATFORM LEVEL UP VALVE - OPEN CIRCUIT
3384 PLATFORM LEVEL UP VALVE - SHORT TO BATTERY
3385 PLATFORM LEVEL UP OVERRIDE VALVE - SHORT TO GROUND
3386 PLATFORM LEVEL UP OVERRIDE VALVE - OPEN CIRCUIT
3387 PLATFORM LEVEL UP OVERRIDE VALVE - SHORT TO BATTERY
3388 PLATFORM LEVEL DOWN VALVE - SHORT TO GROUND
3389 PLATFORM LEVEL DOWN VALVE - OPEN CIRCUIT
3390 PLATFORM LEVEL DOWN VALVE - SHORT TO BATTERY
3391 PLATFORM LEVEL DOWN OVERRIDE VALVE - SHORT TO GROUND
3392 PLATFORM LEVEL DOWN OVERRIDE VALVE - OPEN CIRCUIT
3393 PLATFORM LEVEL DOWN OVERRIDE VALVE - SHORT TO BATTERY
3394 PLATFORM ROTATE LEFT VALVE - SHORT TO GROUND
3395 PLATFORM ROTATE LEFT VALVE - OPEN CIRCUIT
3396 PLATFORM ROTATE LEFT VALVE - SHORT TO BATTERY
3397 PLATFORM ROTATE RIGHT VALVE - SHORT TO GROUND
3398 PLATFORM ROTATE RIGHT VALVE - OPEN CIRCUIT
3399 PLATFORM ROTATE RIGHT VALVE - SHORT TO BATTERY
33100 JIB LIFT UP VALVE - SHORT TO GROUND
33101 JIB LIFT UP VALVE - OPEN CIRCUIT
33102 JIB LIFT UP VALVE - SHORT TO BATTERY
33103 JIB LIFT DOWN VALVE - SHORT TO GROUND
33104 JIB LIFT DOWN VALVE - OPEN CIRCUIT
33105 JIB LIFT DOWN VALVE - SHORT TO BATTERY
33106 TOWER LIFT UP VALVE - SHORT TO GROUND
33107 TOWER LIFT UP VALVE - OPEN CIRCUIT
33108 TOWER LIFT UP VALVE - SHORT TO BATTERY
33109 TOWER LIFT DOWN VALVE - SHORT TO GROUND
33110 TOWER LIFT DOWN VALVE - OPEN CIRCUIT
33111 TOWER LIFT DOWN VALVE - SHORT TO BATTERY
33112 TOWER TELESCOPE IN VALVE - SHORT TO GROUND
33113 TOWER TELESCOPE IN VALVE - OPEN CIRCUIT
33114 TOWER TELESCOPE IN VALVE - SHORT TO BATTERY
33115 TOWER TELESCOPE OUT VALVE - SHORT TO GROUND
33116 TOWER TELESCOPE OUT VALVE - OPEN CIRCUIT
33117 TOWER TELESCOPE OUT VALVE - SHORT TO BATTERY
33118 SWING RIGHT VALVE - SHORT TO GROUND
33119 SWING RIGHT VALVE - OPEN CIRCUIT
33120 TELESCOPE IN VALVE - SHORT TO BATTERY
33121 SWING RIGHT VALVE - SHORT TO BATTERY
33122 SWING LEFT VALVE - SHORT TO GROUND
33123 TELESCOPE OUT VALVE - SHORT TO BATTERY
33124 LIFT UP DUMP VALVE - SHORT TO GROUND
Table 6-5. Fault Codes
DTC Analyzer Text
