SECTION 6 - JLG CONTROL SYSTEM
3121290 – JLG Lift – 6-23
LEVELING MODE:
22*
* Only visible on 800S
models. 0
1
ALL FUNCTIONS: Platform level with all functions.
LEVEL LIFT/TELESCOPE: Platform level on lift and telescope only.
0
DRIVE CONTROL:
23 0
1
2
NORMAL: Drive coils are energized from Ground Module.
PROPULSION: Drive coils are energized from Propulsion Module.
ENHANCED: Drive coils are energized from Ground Module. Ground side of
drive coils are brought back to current feedback returns.
2
BOOM CONTROL:
24 0
1
NORMAL: Boom function coils are energized from Ground Module.
ENHANCED: Boom function coils are energized from Ground Module.
Ground side of drive coils are brought back to current feedback returns.
0
CLEARSKY:
25 0
1
NO: Clearsky (telematics) option is disabled.
YES: Clearsky (telematics) option is enabled.
0
CRIBBING OPTION:
26 0
1
NO: Cribbing Option is disabled.
YES: Cribbing Option is enabled.
0
FUEL TANK SIZE:
27 0
1
31 Gallon Tank
52 Gallon Tank
0
ALARM/HORN:
28 0
1
SEPERATE: Separate alarm and horn.
COMBINED: Combination alarm and horn.
0
4150364E
Table 6-3. Machine Configuration Programming Information Software Version P6.1 to Present
Configuration Label/
Digit
Numb
er
Description
Default
Number
