SECTION 1 - SPECIFICATIONS
3121290 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS AND
PERFORMANCE DATA
1.1 REACH SPECIFICATIONS
1.2 DIMENSIONAL DATA
1.3 CHASSIS
1.4 CAPACITIES
Table 1-1. Operating Specifications
Unrestricted Rated Capacity
ANSI
CE & Australia
500 lb. (227 kg)
500 lb. (230 kg)
Maximum Travel Grade (Grade-
ability)
with Boom retracted and approx-
imately horizontal. Tower Boom
fully lowered (if equipped).
2WD
4WD
30%
45%
Maximum Travel Grade (Sides-
lope) with Boom retracted and
approximately horizontal. Tower
Boom fully lowered (if equipped)
- ANSI Markets. 5°
Maximum Travel Grade (Sides-
lope) with Boom retracted and
approximately horizontal. Tower
Boom fully lowered (if equipped)
- CE & Australia Markets. 4°
Ground Bearing Pressure
Pneumatic
Foam Filled
65 psi (4.57 kg/cm
2
)
65 psi (4.57 kg/cm
2
)
Maximum Drive Speed: 4.5 mph (2.0 m/s)
Maximum Hyd. Operating Pres-
sure 4500 psi (310 Bar)
Electrical System Voltage 12 volts
Table 1-2. Reach Specifications
Max. Platform Height 45ft. (13.72 M)
Max. Horizontal Reach-450A SII 24 ft. 7.25 in. (7.50 M)
Max. Horizontal Reach-450AJ SII 24 ft. 6 in. (7.47 M)
Up & Over Height-450A SII 25 ft. 9.5 in. (7.56 M)
Up & Over Height-450AJ SII 25 ft. 10 in. (7.57 M)
Main Boom Up Angle 75°
Main Boom Down Angle -24°
Table 1-3. Dimensional Data
Overall Width 7 ft. 8.25 in. (2.34 m)
Tailswing 0
Stowed Height 7 ft. 6 in. (2.29 m)
Stowed Length-450A SII 21 ft. 11 in. (6.68 m)
Stowed Length-450AJ SII 22 ft. 0.25 in. (6.71 m)
Wheel base 7 ft. 8 in. (2.34 m)
Ground Clearance 11.5 in. (0.29 m)
Table 1-4. Chassis Specifications
Swing 360° non-continuous
Rated Gradeability
2WD
4WD
30%
45%
Max. Tire Load 7200 lb. (3266 kg)
Axle Oscillation 8 in. (0.2 m)
System Voltage 12 Volts
Max. Hydraulic System Operating
Pressure 4500 psi
(310 bar)
Gross Machine Weight - 450A SII
Pneumatic Tires
Foam-Filled Tires
12,750 lbs. (5783 kg)
13,000 lbs. (5897 kg)
Gross Machine Weight - 450AJ SII
Pneumatic Tires
Foam-Filled Tires
13,250 lbs. (6010 kg)
13,550 lbs. (6146 kg)
Table 1-5. Capacities
Fuel Tank 17 gallons (64.3 liters)
Hydraulic Tank 27 gallons (102 liters)
23.6 gal. (89 liters) to the mid
point of upper sight window
(cold)
Drive Hub 23.75 oz. (0.7 liters)
Drive Brake 2.7 oz. (0.08 liters)
