SECTION 6 - JLG CONTROL SYSTEM
6-12 – JLG Lift – 3121290
Figure 6-8. Analyzer Software Version 6.8 - Sheet 4 of 6
FROM
MENU:
DIAGNOSTICS
TO
PERSONALITIES:
MAIN LIFT
MENU:
SYSTEM TEST
SYSTEM TEST:
ACTIVATE?
MENU:
ACCESS LEVEL
ACCESS LEVEL:
CODE XXXXXX
MENU:
PERSONALITIES
PERSONALITIES:
DRIVE
DRIVE:
ACCEL X.XS
DRIVE:
DECEL X.XS
DRIVE:
MIN FORWARD XXX%
DRIVE:
MAX FORWARD XXX%
DRIVE:
MIN REVERSE XXX%
DRIVE:
MAX REVERSE XXX%
DRIVE:
ELEV. MAX XXX%
DRIVE:
CREEP MAX XXX%
PERSONALITIES:
STEER
STEER:
MAX SPEED XXX%
PERSONALITIES:
LEFT TRACK
LEFT TRACK:
ACCEL X.XS
LEFT TRACK:
DECEL X.XS
LEFT TRACK:
MIN FORWARD XXX%
LEFT TRACK:
MAX FORWARD XXX%
LEFT TRACK:
MIN REVERSE XXX%
LEFT TRACK:
MAX REVERSE XXX%
LEFT TRACK:
ELEV F MAX XXX%
LEFT TRACK:
ELEV R MAX XXX%
LEFT TRACK:
CREEP F MAX XXX%
LEFT TRACK:
CREEP R MAX XXX%
TRACK COUNTER
ROTATE MAX XXX%
TO
MENU:
MACHINE SETUP
PERSONALITIES:
RIGHT TRACK
RIGHT TRACK:
ACCEL X.XS
RIGHT TRACK:
DECEL X.XS
RIGHT TRACK:
MIN FORWARD XXX%
RIGHT TRACK:
MAX FORWARD XXX%
RIGHT TRACK:
MIN REVERSE XXX%
RIGHT TRACK:
MAX REVERSE XXX%
RIGHT TRACK:
ELEV F MAX XXX%
RIGHT TRACK:
ELEV R MAX XXX%
RIGHT TRACK:
CREEP F MAX XXX%
RIGHT TRACK:
CREEP R MAX XXX%
