SECTION 3 - CHASSIS & TURNTABLE
3121290
– JLG Lift –
3-169
DTC 9999- Throttle Actuator Failsafe Spring Failure
• Throttle Actuator
• Check Condition- Key Off, Engine Stopped
• Fault Condition- When key is off (or actuator is unpow-
ered), the ECM is expecting failsafe spring in actuator to
return throttle position to near 0%. If throttle does not
reach this position when actuator is powered, a fault is
generated.
• Corrective Action(s)- Illuminate MIL, sound audible warn-
ing or illuminate secondary warning lamp. Govern engine
speed to a forced idle speed.
• Non-emissions related fault
Throttle actuator has a return spring that causes throttle to
move to a near 0% position when powered off. This causes
engine shutdown following a key off. If ECM detects throttle
position to be above x volts when key is off (as determined by
diagnostic calibration), it will power up the actuator and
attempt to drive it to a zero position. This should ensure
engine is stopped.
Fault sets if throttle does not return to a near 0% position with
key OFF.
Diagnostic Aids
• Disconnect throttle actuator from wire harness. Remove
throttle actuator from engine and manually move it. Verify
internal spring forces throttle back to near 0% position.
• Inspect throttle arm or fuel rack on fuel pump. Verify it is
not stuck.
E
le
c
tro
n
ic
T
h
r
o
ttle
A
c
tu
a
to
r w
/S
e
ria
l
P
o
s
itio
n
F
e
e
d
b
a
c
k
2
1
6
1
3
1
2
1
5
V
_e
x
t
V
s
=
+
5
V
DC
5
V
_
rtn
T
P
S
1
T
P
S
S
ER
+
+
-M
o
to
r
D
B
W-
D
B
W+
E
C
M
H
-B
rid
g
e
1
9
T
P
S
S
ER
-
S
e
ria
l
x
m
itte
r
Electronic Throttle
Actuator w/Serial
Position Feedback
2
16
13
12
1
5V_ext
Vs=+5 VDC
5V_rtn
TPS1
TPS SER +
+
-
Motor
DBW-
DBW+
ECM
H-Bridge
19
TPS SER -
Serial
xmitter
