SECTION 6 - JLG CONTROL SYSTEM
3121290 – JLG Lift – 6-13
Figure 6-9. Analyzer Software Version 6.8 - Sheet 5 of 6
FROM
PERSONALITIES:
RIGHT TRACK
PERSONALITIES:
MAIN LIFT
MAIN LIFT:
ACCEL X.XS
MAIN LIFT:
DECEL X.XS
MAIN LIFT:
MIN UP XXX%
MAIN LIFT:
MAX UP XXX%
MAIN LIFT:
CREEP UP XXX%
MAIN LIFT:
MIN DOWN XXX%
MAIN LIFT:
MAX DOWN XXX%
MAIN LIFT:
CREEP DOWN XXX%
PERSONALITIES:
SWING
SWING:
ACCEL X.XS
SWING:
DECEL X.XS
SWING:
MIN LEFT XXX%
SWING:
MAX LEFT XXX%
SWING:
CREEP LEFT XXX%
SWING:
MIN RIGHT XXX%
SWING:
MAX RIGHT XXX%
SWING:
CREEP RIGHT XXX%
PERSONALITIES:
TOWER LIFT
TOWER LIFT:
ACCEL X.XS
TOWER LIFT:
DECEL X.XS
TOWER LIFT:
MIN UP XXX%
TOWER LIFT:
MAX UP XXX%
TOWER LIFT:
MIN DOWN XXX%
TOWER LIFT:
MAX DOWN XXX%
PERSONALITIES:
MAIN TELESCOPE
MAIN TELESCOPE:
ACCEL X.XS
MAIN TELESCOPE:
DECEL X.XS
MAIN TELESCOPE:
MIN IN XXX%
MAIN TELESCOPE:
MAX IN XXX%
MAIN TELESCOPE:
MIN OUT XXX%
MAIN TELESCOPE:
MAX OUT XXX%
PERSONALITIES:
TOWER TELESCOPE
TOWER TELESCOPE:
ACCEL X.XS
TOWER TELESCOPE:
DECEL X.XS
TOWER TELESCOPE:
MIN IN XXX%
TOWER TELESCOPE:
MAX IN XXX%
TOWER TELESCOPE:
MIN OUT XXX%
TOWER TELESCOPE:
MAX OUT XXX%
PERSONALITIES:
PLATFORM LEVEL
PLATFORM LEVEL:
ACCEL X.XS
PLATFORM LEVEL:
DECEL X.XS
PLATFORM LEVEL:
MIN IN XXX%
PLATFORM LEVEL:
MAX IN XXX%
PLATFORM LEVEL:
MIN OUT XXX%
PLATFORM LEVEL:
MAX OUT XXX%
PERSONALITIES:
PLATFORM ROTATE
PLATFORM ROTATE:
ACCEL X.XS
PLATFORM ROTATE:
DECEL X.XS
PLATFORM ROTATE:
MIN LEFT XXX%
PLATFORM ROTATE:
MAX LEFT XXX%
PLATFORM ROTATE:
MIN RIGHT XXX%
PLATFORM ROTATE:
MAX RIGHT XXX%
PERSONALITIES:
JIB LIFT
JIB LIFT:
ACCEL X.XS
JIB LIFT:
DECEL X.XS
JIB LIFT:
MIN UP XXX%
JIB LIFT:
MAX UP XXX%
JIB LIFT:
MIN DOWN XXX%
JIB LIFT:
MAX DOWN XXX%
PERSONALITIES:
GROUND MODE
GROUND MODE:
MAIN UP: XXX%
GROUND MODE:
MAIN DOWN: XXX%
GROUND MODE:
SWING: XXX%
GROUND MODE:
PLT LEVEL: XXX%
GROUND MODE:
PLT ROTATE: XXX%
GROUND MODE:
MAIN TELE: XXX%
GROUND MODE:
TOWER TELE: XXX%
GROUND MODE:
TOWER UP: XXX%
GROUND MODE:
TOWER DOWN: XXX%
GROUND MODE:
JIB LIFT: XXX%
GROUND MODE:
JIB SWING: XXX%
PERSONALITIES:
GEN SET/WELDER
GEN SET/WELDER:
ENGINE XXXX RPM
