SECTION 6 - JLG CONTROL SYSTEM
3121265 – JLG Lift – 6-37
SYSTEM:
GM BATTERY XX.XV Ground module battery voltage
PM BATTERY XX.XV Platform module battery voltage
AMB. TEMP XXXC Ambient temperature
FSW1 OP/CL Displays footswitch status. NOTE: FSW1 is wired to the ground
module.
FSW2 OP/CL Displays footswitch status. NOTE: FSW2 is wired to the platform
module.
ABOVE ELEV. OP/CL/YES/NO Displays above elevation cutout switch status or above angle sta-
tus
LEN SW 1 OP/CL Displays status of boom length retracted limit switch (Displayed if
MODEL NUMBER = 7 or 8)
LEN SW 2 OP/CL Displays status of boom length retracted limit switch (Displayed if
MODEL NUMBER = 7 or 8)
RETRACTED YES/NO Displays status of boom length retracted (Displayed if MODEL
NUMBER = 7 or 8)
TRANSPORT YES/NO Displays status of transport position
U LIFT CUTOUT OP/CL Displays status of boom length retracted limit switch (Displayed if
MODEL NUMBER = 6)
T LIFT PROX OP/CL Displays status of tower lift proximity switch (Displayed if TOWER
PROX SWITCHES = 1)
T TELE PROX OP/CL Displays status of tower telescope proximity switch (Displayed if
TOWER PROX SWITCHES = 1)
BR CABLE CUT. OP/CL Displays status of broken cable switch (Displayed if BROKEN
CABLE SWITCH = 1)
CREEP ACTIVE/NOT ACTIVE Displays pump pot creep switch status. Not displayed if MODEL =
601 (machine digit = 4)
CRP MODE ACTIVE/NOT ACT Displays creep mode status
SUPER CREEP ON/OFF Displays super creep mode status (Displayed if MODEL NUM-
BER = 7 or 8)
TILT XX.X DEG Displays measured vehicle tilt. (Displayed if internal tilt sensor is
configured)
LO TILTED - NO/YES Displays status of lo tilt input. (Displayed if external tilt sensor is
configured)
Table 6-5. Machine Diagnostics Parameters
Diagnostics
Submenu
(Displayed on
Analyzer 1
st
Line)
Parameter (Displayed
on Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2 nd
Line)
Description
