SECTION 1 - SPECIFICATIONS
3121265 – JLG Lift – 1-5
1.7 MAJOR COMPONENT WEIGHTS 1.8 PRESSURE SETTINGS
Table 1-15. Component Weights
Component Pounds Kilograms
Tire & Wheel 867 393
Drive Hub & Motor 275.5 123
Swing Drive 290 132
Engine Assembly 1275 579
Boom (Complete) 11850 5375
Lift Cylinder 787 357
Tele Cylinder 1322 600
Jib Cylinder 69 31
Axle Oscillation Cylinder 74 34
Axle Extend Cylinder 92 42
Level Cylinder 89 40
Platform 36 x 96 245 111
Platform 36 x 72 195 89
Counterweight 8500 3856
T/T Assy. (less Cwt) 9450 4286
Table 1-16. Pressure Settings
Circuit PSI Bar
Function Pump, High 3400 234.4
Function Pump, Low 300 20.6
Drive, Pre-Set 5000 344.7
Lift Up 2750 189.6
Lift Down 1500 103.4
Swing 1500 103.4
Tele Out 3000 206.8
Telescope In 3200 220.6
Steer Right 2000 137.9
Steer Left 2500 172.3
Platform Level Up 2500 172.3
Platform Level Down 1500 103.4
Jib Up 2750 189.6
Jib Down 2750 189.6
Extendable Axles 2500 172.3
