SECTION 6 - JLG CONTROL SYSTEM
6-22 – JLG Lift – 3121265
SWING: ACCEL X.Xs Displays/adjusts swing acceleration 0.1 to 5.0 sec 2.0
DECEL X.Xs Displays/adjusts swing deceleration 0.1 to 3.0 sec 1.5
MIN LEFT XX% Displays/adjusts minimum swing left
speed 0 to 50% 40
MAX LEFT XXX% Displays/adjusts maximum swing left
speed 0 to 100% 65 115-125
MIN RIGHT XX% Displays/adjusts minimum swing right
speed 0 to 50% 40
MAX RIGHT XXX% Displays/adjusts maximum swing right
speed 0 to 100% 65 115-125
CREEP LEFT XX% Displays/adjusts maximum swing left
speed
NOTE: used when creep switch on
pump pot is active 0 to 65% 50
CREEP RIGHT XX% Displays/adjusts maximum swing right
speed
NOTE: used when creep switch on
pump pot is active 0 to 65% 50
MAIN TELE-
SCOPE: ACCEL X.Xs Displays/adjusts main telescope accel-
eration 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts main telescope decel-
eration 0.1 to 3.0 sec 1.0
MIN IN XX% Displays/adjusts minimum main tele-
scope in speed. Same as Creep speed 0 to 65% 15
MAX IN XXX% Displays/adjusts maximum main tele-
scope in speed 0 to 100% 65 65-75
MIN OUT XX% Displays/adjusts minimum main tele-
scope out speed. Same as Creep speed 0 to 65% 15
MAX OUT XXX% Displays/adjusts maximum main tele-
scope out speed 0 to 100% 60 50-60
BASKET LEVEL: ACCEL X.Xs Displays/adjusts basket level accelera-
tion 0.1 to 5.0 sec 1.5
DECEL X.Xs Displays/adjusts basket level decelera-
tion 0.1 to 3.0 sec 0.5
MIN UP XX% Displays/adjusts minimum basket level
up speed. Same as Creep speed 0 to 65% 40
MAX UP XXX% Displays/adjusts maximum basket level
up speed 0 to 100% 70
MIN DOWN XX% Displays/adjusts minimum basket level
down speed. Same as Creep speed 0 to 65% 40
MAX DOWN XXX% Displays/adjusts maximum basket level
down speed 0 to 100% 70
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON
ANALYZER 2 ND LINE)
DESCRIPTION RANGE
DEFAULT
VALUES
TIME RANGE
(SEC) (SEE
SECTION 6.10
FOR MACHINE
ORIENTATION
WHEN SETTING
SPEEDS)
