Page 308
SECTION 6 - JLG CONTROL SYSTEM
6-24
– JLG Lift –
3121265
GROUND
MODE:
U. LIFT UP XXX%
Displays/adjusts fixed main lift up speed 0 to 100%
60
U. LIFT DN XXX%
Displays/adjusts main lift down speed
0 to 100%
60
SWING XXX%
Displays/adjusts fixed swing speed
0 to 100%
60
BASKET LVL XXX%
Displays/adjusts fixed basket level
speed
0 to 100%
75
BASKET ROT XXX%
Displays/adjusts fixed basket rotate
speed
0 to 100%
75
MAIN TELE XXX%
Displays/adjusts fixed main telescope
speed
0 to 100%
60
TOWER TELE XXX%
Displays/adjusts fixed tower telescope
speed
Not displayed if TOWER TELE=NO
0 to 100%
100
T. LIFT UP XXX%
Displays/adjusts fixed tower lift up
speed
Not displayed if TOWER LIFT=NO
0 to 100%
100
T. LIFT DN XXX%
Displays/adjusts fixed tower lift down
speed
Not displayed if TOWER LIFT=NO
0 to 100%
100
JIB (U/D) XXX%
Displays/adjusts jib lift speed
Not displayed if JIB = 0
0 to 100%
60
JIB (L/R) XXX%
Displays/adjusts jib swing speed
Displayed if JIB = 2
0 to 100%
70
GEN SET/
WELDER:
ENGINE XXXX RPM
Control generator/welder RPM. Not dis-
played if GEN SET/WELDER = 0
1200-2800
1800
4150453-F
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON
ANALYZER 2
ND
LINE)
DESCRIPTION
RANGE
DEFAULT
VALUES
TIME RANGE
(SEC) (SEE
SECTION 6.10
FOR MACHINE
ORIENTATION
WHEN SETTING
SPEEDS)
