SECTION 6 - JLG CONTROL SYSTEM
3121265 – JLG Lift – 6-21
6.9 MACHINE PERSONALITY SETTINGS/
FUNCTION SPEEDS
NOTE: Personality settings can be adjusted within the
adjustment range in order to achieve optimum
machine performance.
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST
LINE)
PARAMETER
(DISPLAYED ON
ANALYZER 2 ND LINE)
DESCRIPTION RANGE
DEFAULT
VALUES
TIME RANGE
(SEC) (SEE
SECTION 6.10
FOR MACHINE
ORIENTATION
WHEN SETTING
SPEEDS)
DRIVE: ACCEL X.Xs Displays/adjusts drive acceleration 0.1 to 5.0 sec 2.0
DECEL X.Xs Displays/adjusts drive deceleration 0.1 to 3.0 sec 1.3
MIN forward XX% Displays/adjusts minimum forward
drive speed 0 to 35% 1
MAX forward XXX% Displays/adjusts maximum forward
drive speed 0 to 100% 100 44-48
MIN reverse XX% Displays/adjusts minimum reverse
drive speed 0 to 35% 1
MAX reverse XXX% Displays/adjusts maximum reverse
drive speed 0 to 100% 100 44-48
ELEV. MAX XX% Displays/adjusts maximum drive speed
NOTE: used when elevation cutout
switches are limiting maximum speed 0 to 50% 25 93-104
CREEP MAX XX% Displays/adjusts maximum drive speed
NOTE: used when creep switch on
pump pot is active 0 to 50% 35 79-87
STEER: max SPEED XXX% Displays/adjusts maximum steer
speed. 0 to 100% 100
MAIN LIFT: ACCEL X.Xs Displays/adjusts main lift acceleration 0.1 to 5.0 sec 1.0
DECEL X.Xs Displays/adjusts main lift deceleration 0.1 to 3.0 sec 1.0
MIN Up XX% Displays/adjusts minimum main lift up
speed 0 to 60% 20
MAX UP XX% Displays/adjusts maximum main lift up
speed 0 to 100% 50 75-100
MIN DOWN XX% Displays/adjusts minimum main lift
down speed 0 to 60% 10
MAX DOWN XXX% Displays/adjusts maximum main lift
down speed 0 to 100% 50 85-110
CREEP UP XX% Displays/adjusts maximum main lift up
speed
NOTE: used when creep switch on
pump pot is active 0 to 65% 50
CREEP DOWN XX% Displays/adjusts maximum main lift
down speed
NOTE: used when creep switch on
pump pot is active 0 to 75% 45
