Galaxy® Gas Analyzer — Operating manual
34
Abb. 24: Calibration set-up
Fig. 24: Calibration set-up
7.4 Calibration method
To access the Calibration screen (see Fig. 25 on p. 34) from the Main screen:
1. Press the Menu key on the instrument panel to open the Main Menu.
2. Press the numeric 3 key to select Calibration. This screen allows you to select the gas you
wish to calibrate:
Abb. 25: Calibration Screen
Fig. 25: Calibration Screen
1 Exhaust to Atmosphere 2 Flow regulator
3 Relief valve 4 Outlet exhaust
5 Calibration gas canister
1
2 3
4
5
Hint!
Before you begin any calibration operations, ensure that the instrument is stabilized at its working
temperature.
Hint!
For details about option 1, Factory Reset (see Reset factory settings on p. 36).
7
Calibration
