25
Galaxy® Gas Analyzer — Operating manual
Abb. 20: View Data Screen 1b
Fig. 20: View Data Screen 1b
5. To return to the first part of the screen, press the Scroll Up key (º/2).
6. To open the View Data Options menu, which allows you to delete, refine or filter the readings
you wish to view, press the left-hand soft key (labeled More in the View Data screen):
Abb. 21: View Data Options Menu
Fig. 21: View Data Options Menu
Delete All data
The instrument can store up to 1000 readings. The reading structure is fixed and may contain
optional parameters not activated for your particular instrument configuration, i.e., oxygen,
temperature and humidity.
When the reading memory is full, it is not possible to store any more readings. If the memory is
full and the Store key is pressed or the Data Logging mode is activated, the instrument will show
a brief message stating that the memory is full and that no further data will be recorded.
The Delete All function allows you to check how many readings have previously been taken and
to clear them from the memory if you so wish. Before the instrument will actually clear the
memory, a caution message will appear on the display, requiring your confirmation.
To access the Delete All function from the Main screen:
1. Press the Menu key on the instrument panel.
2. Press the numeric 4 key to select View Data.
3. Press the left-hand More soft key to display the Options menu.
4. Press the numeric 1 key, then follow the prompt to confirm your wish to clear the memory of
all data records.
Hint!
The sample screen shows Humidity, Temperature 1 & Temperature 2 data read and stored on
January 20, 2009 at 2:12pm, record ID code 00000000, User reading type.
Hint!
Press the right-hand soft key at any time to return to the View Data screen.
Hint!
When readings are deleted, they cannot be recovered.
