43

New Brunswick

Operating Manual

Symptom(s)

Probable Cause(s) & Solution(s)

Shaker is overloaded and/or you are using baffled flasks:
remove some contents & balance load.
Defective motor: call for service.

Shaker does not run at
set speed.

Drive belt out of alignment or worn: call for service.
Load out of balance: unload all contents, then reload.

Operating noise

Loose component(s) in platform, subplatform and/or drive
assembly: call for service.
Heater fuse blown: replace.
Compressor fuse blown: replace.
Compressor over-pressure switch activated: call for service.
Ambient temperature too high or too low: cool or heat the room
as needed.
Defective heater: call for service.
Defective refrigeration system: call for service.

Incubator does not
reach set temperature.

Incorrect temperature indication (see below).
Defective RTD assembly: call for service.

Incorrect temperature
indication.

Defective main board: call for service.

10.2

Replacement Parts

When ordering replacement parts, or requesting service information, please provide the
Model Number and Serial Number of your shaker. This information is on the

ELECTRICAL SPECIFICATION PLATE

, located on the rear panel of the unit. The Serial

Number is also labeled in the lower right corner of the front panel, below the chamber
door seal.

Part Description

Qty Req’d

Part Number

8.0A Fuse (Motor)

1 (I-26)

2 (I-26R)

P0380-3790

15A Circuit Breaker

1

P0400-4305

120V 15A Power Cord

1

P0720-2024

220V Power Cord

1

P0720-2021

Poly-V Belt

1

P0700-7070

Gasket, Door

1

M1324-9508

Damper, Slam-Preventing (gas shock bracket)

2

P0640-0385

AC Connector, Power Entry

1

P0460-2205

Drive Assembly

1

M1324-5010


Belt Replacement Hardware:

Part Description

Qty Req’d

Part Number

3/8-16 NC x 1¼-inch long flat head Allen
screw

3 S1127-3206
