20

I-26/26R Incubator Shakers M1324-0050

Operating Manual

Figure 8: Installing Stacking Kit Brackets

5.7

Stacking the I-26/26R

1. Using a forklift or lifter, raise the I-26/26R to be stacked so that its back end is tilted

toward the rear of the mounting brackets.

2. Remove the feet from the unit. They will not be needed for stacking, but you may

want to keep them for future use.

3. With two assistants, each holding the unit on one side, lower the shaker onto the

mounting brackets, rear panel first. Slowly and gently remove the forklift or lifter
and lower the front of the unit onto the mounting brackets by hand.

Figure 9: Stacked Shakers


STOP BRACKET

STACKING RAILS

Fasten upper shaker
to stacking rails on
both sides and to the
rear stop bracket.
