New Brunswick Operating Manual
5.5 Mounting the I-26/26R on the Optional Base
1. Using a forklift or lifter, raise the I-26/26R so that its back end is tilted toward the
rear of the base.
2. Remove all six feet from the bottom of the shaker. They will not be needed for
stacking, but you may want to keep them for future use.
3. With two assistants, each holding the shaker on one side, lower the unit onto the base,
rear panel first. Slowly and gently remove the forklift or lifter and lower the front of
the unit onto the base by hand.
Optional handles are available to facilitate maneuvering the shaker onto the
base. See Section 10.3.7 for details.
Figure 4: Mounting Shaker on Base
4. Using the ½-13 x 1¼-inch Allen head screws, ½-inch lock washers, and washers
provided, secure the rear of the I-26/26R to the corner braces in the base. With the
remaining ½-13 x 1¼-inch Allen head screws, ½-inch lock washers, and washers,
attach the front corner braces to the unit.
5. Attach the front corner braces to the base using the two sets of ½-13 x 1¼-inch Allen
head screws, lock washers, and washers provided, and secure as shown in Figure 5.
