Temperature Verification System USB – Single-channel — Operating manual

15

4.4 Connecting the Mastercycler pro

1. Use the temperature sensor connecting cable to connect the grip to the Measuring device.
2. Connect the Measuring device and control panel using the USB cable.
3. Switch on the Measuring device.
4. Check the rechargeable battery capacity.
5. Charge the rechargeable battery or use the mains/power supply device if the battery capacity

is low.

1 Probe sockets

2 Measuring device

3 USB interface

4 USB connecting cable

5 USB control panel

6 Grip

7 Temperature probe

6

1

7

ESC

3

2

4

5
