Temperature Verification System USB – Single-channel — Operating manual

14

4.3 Connecting the Mastercycler nexus

1. Use the temperature sensor connecting cable to connect the grip to the Measuring device.
2. Use the USB cable to connect the Measuring device and the Mastercycler.
3. Switch on the Measuring device.
4. Check the rechargeable battery capacity.
5. Charge the rechargeable battery or use the mains/power supply device if the battery capacity

is low.

1 Probe sockets

2 Measuring device

3 USB interface

4 USB connecting cable

5 Mastercycler nexus

6 Grip

7 Temperature probe

6

1

5

7

ESC

2

4

3
