1. Motor frame size must be specified in the body of the order and will no longer
be indicated within the model number.
2. Blade pitch must be indicated in the body of the order.
NEW MODEL NUMBER DESIGNATION
AXICO ® FANS
F __ __ __ - __ - __ __ __ - __ - __ __ - __ __ __ __ - __ __ __
AXICO ® = PAC
= PMC
= PDA
ARR. 4 TYPE 2 =
2 = HORIZONTAL FLOOR LEG
4 = HORIZONTAL CEILING CLIP
6 = VERTICAL CLIP
ARR. 4 TYPE 3
3 = FLOOR MOUNT
FAN SIZE (cm) =
080
090
100
112
125
140
160
180
200
HUB SIZE =
5 = 50.0 cm Dia.
6 = 63.0 cm Dia.
8 = 80.0 cm Dia.
BLADE COUNT =
8 = IF 5 OR 6 HUB
10 = IF 8 HUB
MOTOR RPM =
MOTOR HP =
