12
4. Ensure that all outriggers are fully raised.
5.
Use the Jockey Wheel to raise or lower the tow bar coupling to position the
machine above the 50mm ball hitch on the towing vehicle.
6.
Apply the handbrake.
7.
Lower the tow bar coupling down onto the ball hitch using the Jockey Wheel
8. Secure the breakaway cable,
(Ensure correct engagement of 50mm ball).
9.
Fully raise the Jockey Wheel and lock in position.
10. Release
the Handbrake.
11.
Plug in the trailer lights (7 pin plug) and check that both vehicle and trailer
lights are working correctly.
11
7
6
8 9
TOWING INSTRUCTIONS
