Using the Calibrator Section 3 - Troubleshooting
Page 3-8 067448-003 LX31/LX41 Electric Work Platform
C A L I B R A T O R S E T T I N G S
U P R I G H T T R A C T I O N C O N T R O L L E R D I S P L A Y
LED Function Unit Setting Comments
1 MOS90 Maximum Amp. Capacity Amps 600 Adjustable from 50 amps to 600 amps
2 Acceleration Delay Seconds 1.0 Adjustable from 1.0 sec to 3.0 sec.
3 Deceleration Delay Seconds 0.5 Adjustable from 0.5 sec. to 3.0 sec.
4 Traction Creep % 0 Adjustable from 0% to 10%
5 Max. allowed Speed % 65 Adjustable from 5% to 100%
6 Cutback Speed 1 % 20 Adjustable from 5% to 25%
7 Cutback Speed 2 % 75 Adjustable from 20% to 75%
8 Pump Current limit Amps 270 Adjustable from 50 amps to 600 amps
9 Cutback1 Plug Current Amps 400 Adjustable from 180 amps to 750 amps
10 CSC Proportional Gain 1 30 Adjustable from 1 to 100
11 CSC Integral Gain 1 20 Adjustable from 1 to 100
12 Low Voltage Cutout Volts 25 Adjustable from 25 Volts to 40 Volts
13 Pump Acceleration Delay Seconds 2.0 Adjustable from 1.0 to 3.0
14 Pump Creep % 0% Adjustable from 0% to 30%
Sequence No. Test Display Input #
- Acc. Input 0-100% 14
1 Forward CL/OP 8
2 Reverse CL/OP 11
3 Tach Input 0-100% 12
4 Elev. Pos. CL=Clpsd. 4
OP=Lifted
5 Tilt Switch CL=Level 7
OP=Tilt
6 Pump Switch CL= Pump 16
OP=Trac.
7 Act. Direction OP=FWD 2
Tacho Output CL=REV
8 High/Low Speed CL=High 13
OP=Low
9 Direction Flag OP=No Dr. -
CL=Drv actv.
10 First Error Latch Value= 0-255
Flash Code
NOTE: CL = Switch Closed
OP = Switch Open
