Section 2 - Service and Repair
Torque Hub
067448-003 LX31/LX41 Electric Work Platform
Page 2-21
T
O R Q U E
H
U B
I
N S T A L L A T I O N
IMPORTANT: Hub must be installed with 90° fitting in same position as when it was removed.
NOTE:
Unless otherwise specified, torque all fittings according to
Torque Specifications
in
“Section 1 - General Information”.
1. Install torque hub using ½-20 nuts and ½ washers.
2. Remove plug from 90° fitting and install fitting in side of torque hub. Point fitting towards rear of hub.
3. Using 90 weight gear lube with EP additive, fill torque hub through top plug hole in rear cover until oil
comes out of 90° fitting in side. Plug 90° fitting and top of rear cover.
4. Install new gasket and brake.
5. Install new gasket and electric motor.
6. Secure assembly using washers and bolts.
7. Connect hydraulic brake lines.
8. Connect electric cables.
9. Install wheels. Torque lug nuts to 205 Nm (150 ft. lbs.).
10. Bleed brake lines if necessary.
11. Remove jack stands and lower rear end.
12. Connect battery terminals or Anderson connectors.
13. Check function of brake.
T
O R Q U E
H
U B
S
E A L
R
E P L A C E M E N T
R
OLL
A
ND
L
EAK
T
ESTING
IMPORTANT: Torque hubs should always be roll and leak tested before disassembly and after assembly to make sure
gears and sealants are working properly.
R
OLL
T
EST
Gears should be able to rotate by applying a constant force to the axle. Some gear packages roll with more
difficulty than others.
Do not be concerned if gears seem to roll hard as long as they roll with consistency. If you feel more drag
only at certain points the gears are not rolling freely and should be checked for improper installation or
defects.
L
EAK
T
EST
The purpose of a leak test is to make sure the unit is air tight. Pressurize hub to 0,35 bar (5 PSI). Torque
hub has a leak if the air pressure starts to fall after hub has been pressurized.
Use soap and water on hub to detect location of leaks. If a leak is detected, seal or O-ring must be
replaced.
P
RESSING
T
OOLS
Use pressing tools to remove the seal, cup and cone.
