3.1. Info Center display
The display shows status, warning, and information messages.
3.2. Interlock status indicators
Backlit text indicates the status of the three (3) interlocks: pump engaged, okay to pump, and throttle ready. Throttle
ready and pump engaged are physical inputs into the gray 12-pin connector (pins 2 and 10 respectively) of the TPG+.
Okay to pump becomes active when both the throttle ready and pump engaged interlocks are present.
3.3. Switch panel
The six (6) control switches are color coded and labeled for easy identification.
3.3.1. IDLE
The IDLE switch (red) forces the governor to idle mode (standby). Pressing and holding this button for one
second while in rpm or pressure mode will cause the engine to ramp down to its idle position.
3.3.2. MENU/SILENCE
The MENU/SILENCE switch (blue) is used to silence the alarm, cycle through the display items, and enter the
setup menu.
3.3.3. PRESET
The PRESET switch (orange) sets the governor to the configured preset engine RPM while in throttle mode, or
preset pressure while in pressure mode.
3.3.4. MODE
The MODE switch (green) sets the governor to either throttle mode (RPM) or pressure mode (PSI). The correct
interlocks must be present for the system to begin governor operation: throttle ready for RPM mode, throttle ready,
pump engaged, and okay to pump for PSI mode.
3.3.5. INC
The INC [increase] switch (yellow) is used to increase the engine RPM or pressure set point.
3.3.6. DEC
The DEC [decrease] switch (yellow) is used to decrease the engine RPM or pressure set point.
3.4. Mode indicator
The mode indicator consists of two (2) LEDs to show the governor’s current operating mode. The PSI LED (yellow)
indicates the governor is operating in
pressure mode and the RPM LED (blue) indicates the governor is operating in
throttle mode. When both LEDs are OFF the governor is in idle mode (standby).
3.5. Engine RPM display
The engine RPM display shows the current engine RPM as reported by the Electronic Engine Controller 1 (EEC1)
SAE J1939 network data message transmitted by the vehicle ECU.
