Class1 118711 - TPG+ Governor - 118710 EXTERNAL - Manual (Page 31)

FORM-ENG-0018 REV A 05-27-03
PAGE 30 OF 30
TECHNICAL DATA SHEET
DATE 4/9/2009
PRODUCT GROUP THROTTLE CONTROL P/N 118710 REV 1.00
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-2902 or 1-800-520-3473 PRODUCT TOTAL PRESSURE GOVERNOR PLUS (TPG+) BY AMS
Manual P/N 118711
9. Technical Details
Product category ES-Key network (SAE J1939 CAN)
Voltage range +9VDC…+32VDC
Maximum current draw
@13.8VDC
@27.6VDC
Logic supply+ input (pin 1 of black 12-pin connector)
400 mA
215 mA
Maximum output current
Sensor
(+5VDC) References
Alarm active
250mA (polythermal fuse protected to 300mA)
250mA (ground polarity output)
Temperature range -40ºC…+85ºC
Environmental range IP 67
CAN specification SAE J1939, 250 Kbits/second
LED
3 LEDs each (green/yellow/red) to indicate battery level, water temperature, and oil
pressure status
Electrical protection
Internal thermal fuse (2500mA on pin 1 of black 12-pin connector)
CAN bus protected for heavy duty trucks (24V)
Transient voltage protected to SAE J1113 specification for heavy duty trucks (24V)
Load dump voltage protected to SAE J1113 specification for heavy duty trucks (24V)
Electrical performance
Immunity to Radiated Electromagnetic Fields– Bulk Current
Injection (BCI) method, Class C device
SAE J1113-4
Reverse voltage protection on power leads (pins 1 and 12 of black
12-pin connector), Class C device
ISO 16750-2
Jump start on power leads, Class C device ISO 16750-2
Immunity to conducted transients on power leads, Class C device
(24V)
SAE J1113-11
Immunity to Electrostatic Discharge – powered and unpowered
modes
SAE J1113-13
Immunity to radiated electromagnetic fields SAE J1113-21
Conducted emission on power leads (level 3 limits) SAE J1113-41
Radiated emissions, absorber-lined shielded enclosure (level 2
limits)
SAE J1113-41
Reset behavior on voltage drop 24V, Class C device ISO 16750-2
Environmental performance
Exposure to fungus
MIL-STD-810F
(method 508.5)
SAE J1455
(sec 4.6)
Thermal shock
SAE J1455
(sec 4.1.3.2)
Exposure to humidity
MIL-STD-810F
(method 507.4)
Thermal shock due to splash
Class 1
(STD-0001)
Steam cleaning
SAE J1455
(sec 4.4)
Exposure to salt spray atmosphere/fog
SAE J1455
(sec 4.3)
Exposure to splash due to chemicals and oils
SAE J1455
(sec 4.4)
Exposure to outdoor UV
ISO 4892-2
(method A)
Mechanical performance
Resonance dwell
SAE J1455
(sec 4.9.4.1)
Random vibration
SAE J1455
(sec 4.9.4.2)
Mechanical shock
SAE J1455
(sec 4.10.3.4)
Dimensions (W x H x D)
in inches [millimeters]
7.500 [190.50] x 6.000 [152.40] x 2.312 [58.74]
Weight in ounces [grams] 33.8 [958.2]
