4.6. MENU/SILENCE
switch operation
The MENU/SILENCE switch allows viewing (within the info center display) of the status of engine and pump related
items (section 4.6.1) and silencing of an active alarm (section 4.6.2).
4.6.1. Viewing the engine and pump related items
Press the MENU/SILENCE switch to cycle through the engine and pump related display items (see below).
DISPLAY ITEM FORMAT SOURCE
Battery voltage BAT XX.X Vdc
Input voltage at pins 1(+) and 12 (-) of the black 12-pin
connector.
Engine oil pressure OIL XX PSI SAE J1939 CAN message – PGN 65263
Engine coolant temperature COOLANT XXX°F SAE J1939 CAN message – PGN 65262
Engine oil temperature OIL TMP XXX°F SAE J1939 CAN message – PGN 65262
Transmission oil temperature TRANS XXX°F SAE J1939 CAN message – PGN 65272
Engine fuel rate FUEL X.X G/h SAE J1939 CAN message – PGN 65266
Engine hours ENGINE XXXXh SAE J1939 CAN message – PGN 65253
Pump hours PUMP XX.Xh Internal timer based on pump engaged interlock
TPG+ alarm status ALARM XXX Alarm status
Battery voltage
The info center displays the battery voltage as determined by the TPG+ based upon the voltage applied to pins 1
(+) and 12 (-) of the black 12-pin connector.
Engine oil pressure
The info center displays the engine oil pressure based upon the J1939 CAN message received by the TPG+. The
pressure will be displayed in PSI, kPa, or Bar dependent on the unit of measure configured in the setup menu (see
section 5.2.1).
Engine coolant temperature
The info center displays the engine coolant temperature based upon the J1939 CAN message received by the
TPG+. The temperature will be displayed in degrees Fahrenheit (°F) or degrees Celsius (°C) dependent on the unit
of measure configured in the setup menu (see section 5.2.1).
Engine oil temperature
The info center displays the engine oil temperature based upon the J1939 CAN message received by the TPG+.
The temperature will be displayed in degrees Fahrenheit (°F) or degrees Celsius (°C) dependent on the unit of
measure configured in the setup menu (see section 5.2.1).
