5.2.1. UNITS (unit of measure configuration)
This menu item allows configuration of the display units of measure.
Use the INC and DEC keys to select the desired units of measure. The options include
PSI/ ° F, kPa/ ° C, bar/ ° C.
Range = PSI / ºF, kPa / ºC, bar / ºC [default = PSI / ºF]
5.2.2. PRESET RPM (throttle preset configuration)
This menu item allows configuration of the throttle mode preset.
The display will show
PSETrpm XXXX. Use the INC and DEC switches to adjust the RPM value desired for the
throttle mode preset.
Range = 900 RPM to 1400 RPM (in 25 RPM steps). [default = 1000 RPM]
5.2.3. HI-IDLE (high idle configuration)
This menu item allows configuration of the high idle (fast idle) setpoint.
The display will show
Hi-Idle= XXX. Use the INC and DEC switches to adjust the RPM value desired for the high
idle setpoint.
Range = 900 RPM to 1400 RPM (in 25 RPM steps). [default = 1100 RPM]
5.2.4. PRESET PSI (pressure preset configuration)
This menu item allows configuration of the pressure mode preset.
The display will show
PSETpsi XXX. Use the INC and DEC switches to adjust the PSI value desired for the
pressure mode preset.
Range = 90 PSI to 130 PSI (in 5 PSI steps) [default = 100 PSI]
5.2.5. BRIGHT (display brightness)
This menu item allows configuration of the display’s daytime brightness level.
The TPG+ senses ambient lighting conditions and switches between day/night brightness to compensate. The
display will show
BRIGHT = XX. Use the INC and DEC switches to adjust the value desired display brightness.
Range = 1 to 15 (1 is dimmest setting) [default = 15]
5.2.6. NIGHT (display brightness)
This menu item allows configuration the display’s nighttime brightness level.
The display will show
NIGHT = XX. Use the INC and DEC switches to adjust the value desired display brightness.
Range = 1 to 15 (1 is dimmest setting) [default = 3]
5.2.7. DISPLAY TEST
This menu item allows the user to test all displays and LEDs.
The display will show
DISPLAY TEST. Press either INC or DEC to light all display segments and indicator LEDs.
5.2.8. ROUND PSI
This menu item allows displayed pressure (PSI only, kPa and Bar are not effected) to be rounded by fives.
The display will show
ROUND PSI: X. Use the INC and DEC switches to enable (Yes) or disable (No).
Range = Y (Rounding Enabled) or N (Rounding Disabled). [default = N]
