FORM-ENG-0018 REV A 05-27-03
PAGE 18 OF 30
TECHNICAL DATA SHEET
DATE 4/9/2009
PRODUCT GROUP THROTTLE CONTROL P/N 118710 REV 1.00
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-2902 or 1-800-520-3473 PRODUCT TOTAL PRESSURE GOVERNOR PLUS (TPG+) BY AMS
Manual P/N 118711
Menu items in menu levels 1, 2, 3, and 4
MENU ITEM DESCRIPTION DEFAULT MENU LEVEL
UNITS Configures units of measure PSI / ºF 1
PRESET RPM
Configures the throttle mode (RPM) preset (900 – 1400)
(Not available with message type ANLG)
1000 1*
HI-IDLE
Configures the high idle RPM preset (900-1400)
(Not available with message type ANLG)
1100 1*
PRESET PSI Configures the pressure mode (PSI) preset (90 – 130) 100 1
BRIGHT Configures the display’s brightness level (1-15) 15 1
NIGHT
Configures the secondary brightness level when unit is in a dark
environment (1-15)
3 1
DISPLAY TEST Turns on all LEDs and display segments for visual inspection N/A 1
ROUND PSI Rounds pressure display (PSI units only) by fives NO 1
ALERT TONE
Alert tones are indicated by a double chirp of the alarm output and
do not indicate alarm conditions. Enable/disable the alert tones.
ENABLE 2
SENSITIVITY Configures the pressure sensitivity window +/- 6 PSI 2
-SENSOR CAL- Calibrates the zero point of the intake/discharge pressure sensors 142 COUNTS 2
1ST MODE
Configures the first mode active when the MODE switch is pressed
(interlocks permitting)
PRESSURE 2
COMM STATUS Allows viewing of CAN messages per second and received errors N/A 2
CONTROL Configure control mode and message for engine CFPG (Cummins) 3
AUTO MODE
Configures if governor automatically enters into psi mode upon
pump engagement.
(Only available when 1 st mode menu item is set to PSI)
NO 3*
IDLE STEPS
Sets idle voltage for analog control signal
(Available only with message type ANLG)
32 3*
IDLE RPM
Configure / adjust the idle rpm
(Not available with message type ANLG)
700 3*
MAXIMUM RPM
Configure / adjust the maximum rpm commanded by governor
(Not available with message type ANLG or CFPG)
2400 3*
SOURCE ID
Configure the CAN source ID for the TPG
(only available with message type PGN0 or SCAN)
7 3*
PSI TIME-OUT
Configures the amount of seconds the TPG will wait after pressure
has dropped below 30 PSI before dropping to IDLE mode
5 3
ALLOW PRESET Configure enable/disable rpm preset if pump is under pressure NO 3
WARNINGS
Configures source of the panel warning LED’s (data bus or user
defined) Bus 3
WARN ° F
Configure the yellow (warning) engine temp setpoint
(only available when WARNINGS is set to Usr)
- 3*
CRIT ° F
Configure the red (critical) engine temp setpoint
(only available when WARNINGS is set to Usr)
- 3*
* Option dependent on other menu selections made
