Operation
Whenever you desire to return to idle, press the IDLE switch
with a firm positive switch depression. The message center
will display IDLE REQ and the engine speed will be reduced
to normal idle. This clears the governor of any pressure or
RPM set points and [MODE] will be displayed in the mes-
sage center.
I D L E R E Q
[ M O D E ]
The PRESET switch can be used anytime after an operating
mode has been chosen to promptly bring the engine or pump
to the preset point.
The message center will display -PRESET- while the engine
is being adjusted and then either RPM or PSI will be dis-
played dependent on the operating mode selected.
- P R E S E T -
R P M MODE
P S I MODE
[ M O D E ]
While the governor is powered up and the OEM Throttle In-
terlock is active, a remote High Idle function is available. A
12 volt input is available to activate this feature.
This feature will not activate if a governing mode has been
selected, the pump engaged interlock is active or the throttle
interlock is lost. If the High Idle is active, it will drop out if the
pump is engaged or the throttle interlock is lost. While the
high idle feature is active, HighIdle will be displayed in the
message center. The INC and DEC switches are active in
the High Idle Mode.
