24
ISC Wiring
Reference Voltage C12-1 Reference Ground C12-9
Control Signal C12-8
Delay Rly 30 C12-11 Delay Rly 87 C12-12
Cummins ISCWiring
B-10 +5VDC B-20 Throttle Return B-9 Remote Throttle B-45 Remote Thottle ON
/
Ground
Important
: This governor version incorporates the Engine 5 Volt and Ground Reference
s
IT WILL NOT OPERATE without these circuits wired as shown.
Any questions should be directed to Class1 Support at 1-800-533-3569
Cummins ISC Governor Wiring Revision
C
onnector
DT06-4S
T
erminal
Sockets
P
osition
Wire Color
Description
1
RED
+ 12 VDC
2
Black
Ground
3
Plug
NC
4
Plug
NC
C
onnector
DT06-12S
T
erminal
Sockets
P
osition
Wire Color
Description
1
Red
+ 5 VDC
2
White
OEM Interlock
3
White
High Idle
4
Brown
NC
5
Black
Sensor Ground
6
Red
Sensor V
oltage
7
White
Sensor Signal
8
Y
ellow
Control Signal
9
Black
Throttle Return
10
White
PT
O Interlock
1
1
Orange
Enable Input
12
Blue
Enable Output
4-1 12 VDC 4-2 Ground
Pump
Engag
e
OE
Interl
o
FAST IDLE
High Idle C12-3
Throttle Ready C12-2
Pump Engaged C12-10
Throttl
e
Read
y
ECU Power
High Idle Switch
Sensor Ground C12-5 Sensor V
oltage C12-6
Sensor Signal C12-7
A
Black
Ground
B Red
+5 VDC
C White
Signal
T
rans
d
Conne
Pressure Governor
RED BLACK
