C2 infinity connector c2, Pin wire color gauge, Description – AEM 30-3532 GM LS 24x Engines Layover User Manual
Page 9: C3 coil b1, C4 coil b2
Rev A, 2013/02/05
C2
Infinity Connector C2
56 Way F Receptacle 0.64 2.8 Series Sealed (BU)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
C2-3
BLK
18
SP-1
---
---
---
---
Battery Ground
C2-4
RED/BLK
20
C11-B
---
---
---
---
Injector 7 Control Lowside
C2-5
DK BLU/WHT
20
C12-B
---
---
---
---
Injector 8 Control Lowside
C2-8
BRN
20
C4-E
---
---
---
---
Coil Signal Ground (Bank 2)
C2-9
PNK/YEL
20
SP-4
---
---
---
---
ECU 12V from EFI-1
C2-13
---
---
---
---
---
---
---
Optional Drive-by-Wire (AccPedalPosition-2)
C2-14
---
---
---
---
---
---
---
Optional Drive-by-Wire (AccPedalPosition-1)
C2-18
GRN
20
C25-C
---
---
---
---
AEM Oil Pressure Sensor Signal
C2-21
---
---
---
---
---
---
---
Optional Drive-by-Wire (TPS1B)
C2-22
GRY
20
C13-C
---
---
---
---
MAP Sensor 5V Supply
C2-23
GRY
20
C16-A
---
---
---
---
TPS 5V Supply
C2-24
GRY
20
C25-B
---
---
---
---
Oil Pressure Sensor 5V Supply
C2-29
ORN/WHT
20
1' Flying Lead
---
---
---
Tacho Signal Out (1' flying lead)
C2-30
BLK, PPL
20
C25-A
C24-A
---
---
---
Sensor Ground
C2-31
TAN, BLK
20
C19-A
C16-B
---
---
---
Sensor Ground
C2-32
ORN/BLK
20
C13-A
---
---
---
---
MAP Sensor Ground
C2-34
---
---
---
---
---
---
---
Optional Drive-by-Wire (TPS2A)
C2-36
---
---
---
---
---
---
---
Optional Drive-by-Wire (TPS2B)
C2-39
BLK
18
SP-1
---
---
---
---
Battery Ground
C2-40
BLK
18
SP-1
---
---
---
---
Battery Ground
C2-45
ORN
20
C27-5
---
---
---
---
Deutsch DTM04-6P UEGO B2-VM
C2-46
BLK
20
C27-1
---
---
---
---
Deutsch DTM04-6P UEGO B2-UN
C2-47
RED
20
C27-6
---
---
---
---
Deutsch DTM04-6P UEGO B2-IP
C2-48
GRN
20
C27-2
---
---
---
---
Deutsch DTM04-6P UEGO B2-IA
C2-49
WHT
18
C27-4
---
---
---
---
Deutsch DTM04-6P UEGO B2-HEAT
C2-50
PNK/RED
---
P1-7A
---
---
---
---
12V Perm Power
C2-51
RED
20
C3-B
---
---
---
---
Coil 7
C2-52
PPL/WHT
20
C4-G
---
---
---
---
Coil 8
C3
Coil B1
7 Way F Metri-Pack 150 Series Sealed (Cream)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
BLK
16
SP-1
---
---
---
---
Power Ground
B
RED
20
C2-51
---
---
---
---
IC 7 Control
C
DK GRN
20
C1-16
---
---
---
---
IC 5 Control
D
---
---
---
---
---
---
---
Not Used
E
BRN
20
C1-30
---
---
---
---
Signal Ground
F
LT BLU
20
C1-12
---
---
---
---
IC 3 Control
G
PPL
20
C1-14
---
---
---
---
IC 1 Control
H
PNK
16
SP-5
---
---
---
---
Ignition Voltage
C4
Coil B2
7 Way F Metri-Pack 150 Series Sealed (Cream)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
BLK
16
SP-1
---
---
---
---
Power Ground
B
RED/WHT
20
C1-13
---
---
---
---
IC 2 Control
C
DK GRN/WHT
20
C1-11
---
---
---
---
IC 4 Control
D
---
---
---
---
---
---
---
Not Used
E
BRN
20
C2-8
---
---
---
---
Signal Ground
F
LT BLU/WHT
20
C1-15
---
---
---
---
IC 6 Control
G
PPL/WHT
20
C2-52
---
---
---
---
IC 8 Control
H
PNK
16
SP-6
---
---
---
---
Ignition Voltage
