C14 maf sensor, Pin wire color gauge, Description – AEM 30-3532 GM LS 24x Engines Layover User Manual
Page 11: C15 idle air control motor, C16 throttle position sensor, C17 crank position sensor, C18 cam position sensor, C19 engine coolant temp sensor, C20 knock sensors, C21 alternator
Rev A, 2013/02/05
C14
MAF Sensor
3 Way F Metri-Pack 150 Series (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
YEL
20
C1-24
---
---
---
---
MAF Sensor Signal
B
BLK
20
SP-3
---
---
---
---
Ground
C
PNK
20
SP-7
---
---
---
---
Ignition Voltage
C15
Idle Air Control Motor
4 Way F Metri-Pack 150.2 Series Pull to Seat
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
LT GRN/BLK
20
C1-71
---
---
---
---
IAC Stepper Motor Coil B LOW
B
LT GRN/WHT
20
C1-69
---
---
---
---
IAC Stepper Motor Coil B HIGH
C
LT BLU/BLK
20
C1-72
---
---
---
---
IAC Stepper Motor Coil A LOW
D
LT BLU/WHT
20
C1-70
---
---
---
---
IAC Stepper Motor Coil A HIGH
C16
Throttle Position Sensor
3 Way F Metri-Pack 150 Series Pull to Seat (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
GRY
20
C2-23
---
---
---
---
5-Volt Reference
B
BLK
20
C2-31
---
---
---
---
Sensor Ground
C
DK BLU
20
C1-35
---
---
---
---
TPS Sensor Signal
C17
Crank Position Sensor
3 Way F Metri-Pack 150 Series (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
DK BLU/BLK
20
C1-21
---
---
---
---
CKP Sensor Signal
B
YEL/BLK
20
C1-19
---
---
---
---
Sensor Ground
C
GRY
20
C1-41
---
---
---
---
5-Volt Reference
M
Mesh
---
C1-55
---
---
---
---
Shielding Drain
C18
Cam Position Sensor
3 Way F Metri-Pack 150 Series (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
BRN/WHT
20
C1-22
---
---
---
---
CMP Sensor Signal
B
PNK/BLK
20
C1-20
---
---
---
---
Sensor Ground
C
GRY
20
C1-42
---
---
---
---
5-Volt Reference
M
Mesh
---
C1-55
---
---
---
---
Shielding Drain
C19
Engine Coolant Temp Sensor
2 Way F Metri-Pack 150.2 Series Sealed P2S (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
TAN
20
C2-31
---
---
---
---
Sensor Ground
B
YEL
20
C1-66
---
---
---
---
ECT Sensor Signal
C20
Knock Sensors
2 Way F Metri-Pack 150 Series Sealed (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
DK BLU
20
C1-27
---
---
---
---
Knock Sensor 1 Signal
B
LT BLU
20
C1-28
---
---
---
---
Knock Sensor 2 Signal
C21
Alternator
4 Way F Metri-Pack 150 Series Sealed (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
Not Used
---
---
---
---
---
---
B
RED
20
C1-44
---
---
---
---
12V High Side Driver -> 470Ω -> Alternator
C
Not Used
---
---
---
---
---
---
D
Not Used
---
---
---
---
---
---
