AEM 30-3532 GM LS 24x Engines Layover - Manual (Page 8)

Rev A, 2013/02/05
GM LS Engines 24x Pinout
C1 Infinity Connector C1
73 Way F Receptacle 0.64 2.8 Series Sealed (GY)
Pin Wire Color Gauge
Destination
Description
1 2 3 4 5
C1-2 GRN 20 C23-B --- --- --- --- Reverse Lockout Lowside Driver
C1-4 WHT 18 C26-4 --- --- --- --- Deutsch DTM04-6P UEGO B1-HEAT
C1-5 GRN 20 C26-2 --- --- --- --- Deutsch DTM04-6P UEGO B1-IA
C1-6 RED 20 C26-6 --- --- --- --- Deutsch DTM04-6P UEGO B1-IP
C1-7 BLK 20 C26-1 --- --- --- --- Deutsch DTM04-6P UEGO B1-UN
C1-8 ORN 20 C26-5 --- --- --- --- Deutsch DTM04-6P UEGO B1-VM
C1-10 PNK/RED 20 P1-7A --- --- --- --- 12V Perm Power
C1-11 DK GRN/WHT 20 C4-C --- --- --- --- Coil 4
C1-12 LT BLU 20 C3-F --- --- --- --- Coil 3
C1-13 RED/WHT 20 C4-B --- --- --- --- Coil 2
C1-14 PPL 20 C3-G --- --- --- --- Coil 1
C1-15 LT BLU/WHT 20 C4-F --- --- --- --- Coil 6
C1-16 DK GRN 20 C3-C --- --- --- --- Coil 5
C1-17 VIO 20 P1-5D --- --- --- --- Radiator Fan 1 Relay Control Lowside
C1-18 VIO/BLK 20 P1-7D --- --- --- --- Radiator Fan 2 Relay Control Lowside
C1-19 YEL/BLK 20 C17-B --- --- --- --- Crank Position Sensor Ground
C1-20 PNK/BLK 20 C18-B --- --- --- --- Cam Position Sensor Ground
C1-21 DK BLU/BLK 20 C17-A --- --- --- --- Crank Position Sensor Signal
C1-22 BRN/WHT 20 C18-A --- --- --- --- Cam Position Sensor Signal
C1-24 YEL 20 C14-A --- --- --- --- Mass Air Flow Sensor Signal
C1-27 DK BLU 20 C20-A --- --- --- --- Knock Sensor Signal 1
C1-28 LT BLU 20 C20-B --- --- --- --- Knock Sensor Signal 2
C1-29 YEL/WHT 20, 20 P1-1D P1-3D --- --- --- EFI-1 Relay/EFI-2 Relay Control Lowside
C1-30 BRN 20 C3-E --- --- --- --- Coil Signal Ground (Bank 1)
C1-31 GRN 22 C28-2 --- --- --- --- CAN Low (twisted pair)
C1-32 WHT 22 C28-1 --- --- --- --- CAN High (twisted pair)
C1-34 VIO/WHT 20 P1-9D --- --- --- --- Fuel Pump Relay Control Lowside
C1-35 DK BLU 20 C16-C --- --- --- --- Throttle Position Sensor Signal
C1-36 LT GRN 20 C13-B --- --- --- --- Manifold Absolute Pressure Signal
C1-41 GRY 20 C17-C --- --- --- --- Crank Position Sensor +5V Supply
C1-42 GRY 20 C18-C --- --- --- --- Cam Position Sensor +5V Supply
C1-44 RED 20 C21-B --- --- --- --- 12V High Side Driver -> 470Ω -> Alternator
C1-55 MESH --- C17-M C18-M --- --- --- Ground for Cam/Crank wire shieldings (drains)
C1-56 YEL/BLK 20 C10-B --- --- --- --- Injector 6 Control Lowside
C1-57 BLK/WHT 20 C9-B --- --- --- --- Injector 5 Control Lowside
C1-58 LT BLU/BLK 20 C8-B --- --- --- --- Injector 4 Control Lowside
C1-59 PNK/BLK 20 C7-B --- --- --- --- Injector 3 Control Lowside
C1-60 BLK 20 C28-4 --- --- --- --- AEMnet Ground
C1-61 PNK/YEL 20 SP-4 --- --- --- --- ECU 12V from EFI-1
C1-62 LT GRN/BLK 20 C6-B --- --- --- --- Injector 2 Control Lowside
C1-63 BLK 20 C5-B --- --- --- --- Injector 1 Control Lowside
C1-64 PNK/YEL 20 SP-4 --- --- --- --- ECU 12V from EFI-1
C1-65 PNK/WHT 20 1' flying lead for ign switch 12V Switched Ignition
C1-66 YEL 20 C19-B --- --- --- --- Engine Coolant Temperature Sensor Signal
C1-67 TAN 20 C24-B --- --- --- --- Intake Air Temperature Sensor Signal
C1-69 LT GRN/WHT 20 C15-B --- --- --- --- IAC Stepper Motor Coil B High
C1-70 LT BLU/WHT 20 C15-D --- --- --- --- IAC Stepper Motor Coil A High
C1-71 LT GRN/BLK 20 C15-A --- --- --- --- IAC Stepper Motor Coil B Low
C1-72 LT BLU/BLK 20 C15-C --- --- --- --- IAC Stepper Motor Coil A Low
C1-73 BLK 14 SP-1 --- --- --- --- Battery Ground
