C22 vehicle speed sensor, Pin wire color gauge, Description – AEM 30-3532 GM LS 24x Engines Layover User Manual
Page 12: C23 reverse lockout solenoid, C24 intake air temp sensor, C25 aem oil pressure sensor, C26 uego sensor bank 1, C27 uego sensor bank 2, C28 can
Rev A, 2013/02/05
C22
Vehicle Speed Sensor
2 Way F Metri-Pack 150.2 Series Pull to Seat (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
GRY/BLK
20
C2-26
---
---
---
---
Vehicle Speed Signal LOW
B
PPL/WHT
20
C2-25
---
---
---
---
Vehicle Speed Signal HIGH
C23
Reverse Lockout Solenoid
2 Way F Metri-Pack 150 Series Sealed (WHT)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
PNK
20
P1-10A
---
---
---
---
Ignition Voltage
B
GRN
20
C1-2
---
---
---
---
Reverse Lockout Signal (lowside driver)
C24
Intake Air Temp Sensor
2 Way F Metri-Pack 150.2 Series Pull to Seat (GRY)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
PPL
20
C2-30
---
---
---
---
Sensor Ground
B
TAN
20
C1-67
---
---
---
---
IAT Sensor Signal
C25
AEM Oil Pressure Sensor
3 Way F Metri-Pack 150 Series (BLK)
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
A
BLK
20
C2-30
---
---
---
---
Sensor Ground
B
GRY
20
C2-24
---
---
---
---
5V Reference
C
GRN
20
C2-18
---
---
---
---
Sensor Signal
C26
UEGO Sensor Bank 1
Deutsch DTM04-6P
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
1
BLK
20
C1-7
---
---
---
---
UEGO UN 1
2
GRN
20
C1-5
---
---
---
---
UEGO IA 1
3
BRN
18
SP-5
---
---
---
---
UEGO +12V 1
4
WHT
18
C1-4
---
---
---
---
UEGO HEAT 1
5
ORN
20
C1-8
---
---
---
---
UEGO VM 1
6
RED
20
C1-6
---
---
---
---
UEGO IP 1
C27
UEGO Sensor Bank 2
Deutsch DTM04-6P
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
1
BLK
20
C2-46
---
---
---
---
UEGO UN 2
2
GRN
20
C2-48
---
---
---
---
UEGO IA 2
3
BRN
18
SP-6
---
---
---
---
UEGO +12V 2
4
WHT
18
C2-49
---
---
---
---
UEGO HEAT 2
5
ORN
20
C2-45
---
---
---
---
UEGO VM 2
6
RED
20
C2-47
---
---
---
---
UEGO IP 2
C28
CAN
Deutsch DTM04-4P
Pin
Wire Color
Gauge
Destination
Description
1
2
3
4
5
1
WHT
20
C1-32
---
---
---
---
CAN_High (twisted pair)
2
GRN
20
C1-31
---
---
---
---
CAN_Low (twisted pair)
3
RED
20
SP-7
---
---
---
---
AEMnet 12V Supply
4
BLK
20
C1-60
---
---
---
---
AEMnet Ground
