AEM 30-2340 4-Channel Wideband UEGO AFR Controller - Manual (Page 29)

Page 29 10-2340 Rev 05 121012
2 (bit7)
AFR 6 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
3 --- --- --- --- ---
4 (bit0)
UEGO Low Voltage Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit1)
EBP sensor ready
Boolean 0 = false, 1 = true 0 0/1
4 (bit2)
EBP sensor Error Low Volt
Boolean 0 = false, 1 = true 0 0/1
4 (bit3)
EBP sensor detected
Boolean 0 = false, 1 = true 0 0/1
4 (bit4) CAN Config Mode Boolean 0 = false, 1 = true 0 0/1
4 (bit5)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit6)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit7)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
5 (bit0) --- --- --- --- ---
5 (bit1) --- --- --- --- ---
5 (bit2) --- --- --- --- ---
5 (bit3) --- --- --- --- ---
5 (bit4) --- --- --- --- ---
5 (bit5)
Sensor 6 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit6)
Sensor 5 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit7)
Sensor 4 Heating up
Boolean 0 = false, 1 = true 0 0/1
6
Exhaust Pressure 2 16 bit unsigned .001 psig/bit 0 0 to 655.35 psig
7
