AEM 30-2340 4-Channel Wideband UEGO AFR Controller User Manual
Page 27
Page 27 10-2340 Rev 05 121012
4 (bit2)
EBP sensor Error Low Volt
Boolean
0 = false, 1 = true
0
0/1
4 (bit3)
EBP sensor detected
Boolean
0 = false, 1 = true
0
0/1
4 (bit4)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit5)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit6)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit7)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
5 (bit0)
---
---
---
---
---
5 (bit1)
---
---
---
---
---
5 (bit2)
---
---
---
---
---
5 (bit3)
---
---
---
---
---
5 (bit4)
Sensor 12 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit5)
Sensor 11 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit6)
Sensor 10 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit7)
Sensor 9 Heating up
Boolean
0 = false, 1 = true
0
0/1
6
Exhaust Pressure 2
16 bit unsigned
.001 psig/bit
0
0 to 655.35 psig
7
Message ID:
0x000001B4
Source:
AEM 4 Channel UEGO set on MODE 6
Rate:
40ms continuous
Byte
Label
Data Type
Scaling
Offset
Range
0 (bit0)
AFR 1 Ready
Boolean
0 = false, 1 = true
0
0/1
0 (bit1)
AFR 1 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit2)
AFR 1 VM Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit3)
AFR 1 UN Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit4)
AFR 1 IP Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit5)
AFR 1 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit6)
AFR 1 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit7)
AFR 1 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit0)
AFR 2 Ready
Boolean
0 = false, 1 = true
0
0/1
1 (bit1)
AFR 2 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit2)
AFR 2 VM Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit3)
AFR 2 UN Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit4)
AFR 2 IP Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit5)
AFR 2 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit6)
AFR 2 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit7)
AFR 2 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit0)
AFR 3 Ready
Boolean
0 = false, 1 = true
0
0/1
2 (bit1)
AFR 3 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit2)
AFR 3 VM Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit3)
AFR 3 UN Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit4)
AFR 3 IP Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit5)
AFR 3 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit6)
AFR 3 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit7)
AFR 3 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
