Page 23 10-2340 Rev 05 121012
1 (bit7)
AFR 6 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit0)
AFR 7 Ready
Boolean 0 = false, 1 = true 0 0/1
2 (bit1)
AFR 7 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit2)
AFR 7 VM Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit3)
AFR 7 UN Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit4)
AFR 7 IP Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit5) AFR 7 Heater Time-Out Error Boolean 0 = false, 1 = true 0 0/1
2 (bit6)
AFR 7 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit7)
AFR 7 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit0)
AFR 8 Ready
Boolean 0 = false, 1 = true 0 0/1
3 (bit1)
AFR 8 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit2)
AFR 8 VM Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit3)
AFR 8 UN Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit4)
AFR 8 IP Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit5)
AFR 8 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit6)
AFR 8 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit7)
AFR 8 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit0)
UEGO Low Voltage Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit1)
EBP sensor ready
Boolean 0 = false, 1 = true 0 0/1
4 (bit2)
EBP sensor Error Low Volt
Boolean 0 = false, 1 = true 0 0/1
4 (bit3)
EBP sensor detected
Boolean 0 = false, 1 = true 0 0/1
4 (bit4)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit5)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit6)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit7)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
5 (bit0)
Reserved
Boolean 0 = false, 1 = true 0 0/1
5 (bit1)
Reserved
Boolean 0 = false, 1 = true 0 0/1
5 (bit2)
Reserved
Boolean 0 = false, 1 = true 0 0/1
5 (bit3)
Reserved
Boolean 0 = false, 1 = true 0 0/1
5 (bit4)
Sensor 8 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit5)
Sensor 7 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit6)
Sensor 6 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit7)
Sensor 5 Heating up
Boolean 0 = false, 1 = true 0 0/1
6
Exhaust Pressure 2 16 bit unsigned .001 psig/bit 0 0 to 655.35 psig
7
Message ID: 0x000001B1
Source: AEM 4 Channel UEGO set on MODE 3
Rate: 40ms continuous
Byte Label Data Type Scaling Offset Range
0 (bit0)
AFR 1 Ready
Boolean 0 = false, 1 = true 0 0/1
0 (bit1)
AFR 1 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit2)
AFR 1 VM Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit3)
AFR 1 UN Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit4)
AFR 1 IP Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit5)
AFR 1 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
