Berkeley Nucleonics
www.Berkeley Nucleonics.com

835-3

Programmer’s Manual v1.0

Page 27 of 37


:STARt
[SOURce]:POWer:STARt
[SOURce]:POWer:STARt?
This command sets the first amplitude point in a step sweep.
*RST ?
Range Refer to

[:LEVel][:IMMediate][:AMPLitude]

command for the output power

ranges.

:STOP
[SOURce]:POWer:STOP
[SOURce]:POWer:STOP?
This command sets the last amplitude point in a step sweep.
*RST ?
Range Refer to

[:LEVel][:IMMediate][:AMPLitude]

command for the output power

ranges.

[SOURce]:AM Subsystem (Amplitude Modulation)

Command

Parameters

Unit (default)

[SOURce]:AM:DEPTh

0.8 (80 PCT)

[SOURce]:AM:STATe

ON|OFF|1|0

[SOURce]:AM:INTernal:FREQuency

400 Hz


:AM:INT:FREQuency
[SOURce]:AM:INTernal:FREQuency |UP|DOWN
[SOURce]:AM:INTernal:FREQuency?
This command sets the internal amplitude modulation rate.
*RST 400 Hz
Range 400 Hz and 1000 Hz

The RF carrier is modulated when you have set the signal generator’s AM modulation
state to ON.
Whenever amplitude modulation is enabled, the AM on is in the display.

:AM:DEPTh
[SOURce]:AM[:DEPTh]:
[SOURce]:AM[:DEPTh]:?
This command sets the amplitude modulation depth 0...1.
*RST 0.8
Range 0-0.99

[SOURce]:FM Subsystem (Frequency Modulation)

8

Command

Parameters

Unit (default)

[SOURce:]FM:DEViation

10000 Hz

[SOURce:]FM:SENSitivity

10000 Hz/V

[SOURce:]FM:SOURce

EXTernal|LFGenerator

EXT

[SOURce:]FM:STATe

ON|OFF|1|0

OFF
