1. G
ENERAL INFORMATION
1.1. Overview
The MOD745-20 Digital Delay Generator provides twenty independent delayed output pulses.
Delays up to 10 seconds may be programmed with 100ps resolution (1ps optional) and a channel to
channel jitter of less than 50 ps RMS.
BNC outputs deliver delayed pulses with adjustable level (3 to 6V) and width into 50 Ω load. A polarity
control allows to have inverted pulses.
A trigger output signal (T0) is provided as the temporal reference for the delayed outputs.
The MOD745-20 may be remote controlled via Ethernet interface (10/100Mb/s) (basic commands or Web
page interface).
Instrument Options
Option 1 Clock output (same frequency as specified clock input)
Option 2 2.5 to 10 V channels, 1 ns rise time, positive polarity
Option 3 Amplitude up to 20 V, adjustable
Option 4 Maximum amplitude up to 32V (fixed)
Option 5 1 ps resolution
Option 6 Front panel for local control (touchscreen)
Other Trigger source saved after shut down, Immediate modification of output pulse without
validation, specific options available upon request.
Package contents
The box you receive should contain the following:
o MOD745-20 instrument,
o Power cable,
o User’s manual,
o CD containing DLL and Labview driver.
Berkeley Nucleonics products
For more information about
Berkeley Nucleonics products see our web site:
