User's Manual - MOD745-20 October 2014
Page 16 / 30
5.5. Sub-
menu “Frequency”
Tapping in the “F1”, “F2” or “F3” window on the “INTERNAL FREQUENCIES SETUP” sub-menu will open
another sub-menu with the corresponding frequency settings depicted in the following figure.
To set the frequency, enter the value with the numbers, then tapping on the unit (Hz or KHz) validate the
setting.
Erase
Exit sub-menu
Notes:
- Out of range values are rejected.
- The frequency values can be set in a 1 – 2 – 5 sequence.
- F1 > F2 > F3 and minimum gap of 2 between F1 and F2 or F2 and F3.
5.6. Sub-
menu “NETWORK ADDRESS SETUP”
Tapping in the “STATUS” window on the main menu will open a sub-menu with the network address
setup as depicted in the following figure.
