User's Manual - MOD745-20 October 2014
Page 29 / 30
7. S
OFTWARE
The MOD745-20 comes with DLL drivers for Windows XP or Seven. Our primary objective in designing
software drivers is to get the user up and running as quickly as possible.
Software drivers are provides as a Dynamic Link Library (DLL) which is compatible with most 32-bit
windows based development software. The main program is written on Labview v11 or later.
The listing of files is the following:

MOD745-20: main program,

DLL or vi:
o *.dll or *.vi : set the value,
o *_val.dll or *_val.vi : query the value.
Delay
void Delay(LVRefNum *IDConnexionIN, uInt8 Channel, floatExt DelayPs, TD1 *entrEDErreurPasDErreur,
LVRefNum *IDDeConnexionOUT, TD1 *errorOut)
Delay_val
void Delay_val(LVRefNum *IDConnexionIN, uInt8 Channel, TD1 *entrEDErreurPasDErreur, LVRefNum
*IDDeConnexionOUT, uInt8 *ChannelOut, floatExt *DelayPs, TD1 *errorOut)
Identifiant_val
void
Identifiant_val(LVRefNum *IDConnexionIN, TD1 *entrEDErreurPasDErreur, LVRefNum
*IDDeConnexionOUT, LStrHandle *dataOut, TD1 *errorOut)
Softtrigger
void
Softtrigger(LVRefNum *IDConnexionIN, TD1 *entrEDErreurPasDErreur, LVRefNum
*IDDeConnexionOUT, TD1 *errorOut)
Trigger
void Trigger(LVRefNum *IDConnexionIN, uInt8 Channel, uInt16 Trigger2, TD1 *entrEDErreurPasDErreur,
LVRefNum *IDDeConnexionOUT, TD1 *errorOut)
trigger_val
void Trigger_val(LVRefNum *IDConnexionIN, uInt8 Channel, TD1 *entrEDErreurPasDErreur, LVRefNum
*IDDeConnexionOUT, uInt8 *ChannelOut, uInt16 *TriggerOut, TD1 *errorOut)
sta_val
void
Sta_val(LVRefNum *IDConnexionIN, TD1 *entrEDErreurPasDErreur, LVRefNum
*IDDeConnexionOUT, TD2Hdl *Surveillance, TD1 *errorOut)
