User's Manual - MOD745-20 October 2014
Page 28 / 30
The “SYNC MESSAGE” area allows to:
- Change the values of F1 to F3
- Toggl e between Run and Stop states (“Run” button lights green when in “Run” state)
- Perform a single shot (“Trigger” button lights green when a single shot occurred, and can be erased
by clicking on the state led of the channels)
The “STATUS” area shows:
- The level of the internal power supplies
- The internal temperature of the unit
- The state of the clock (lights in green when external clock)
Notes: When entering a new value, after pressing “Enter” key, the field turns yellow briefly (the new value
is sent), then turns white again (the new value has been taken into account). If the new value is out of range,
then the field will turn red, until a valid value is entered.
