34.13
Removing and installing ABS brake
line from front pressure modulator
• Remove knee pads.
• Remove fuel tank.
• Release screw connections (1,2).
• Release connections at pressure modulator (3).
• Remove both lines together.
• Release spacer (4) and replace defective line.
• Install the reverse order of removal.
X
Tightening torques:
Screw connection ........................................ 18 Nm
Line to pressure modulator .......................... 18 Nm
LT340110
1
2
3
4
