ASYNC ROUTER AR-P, AR-5, AND SYNC ROUTER REFERENCE MANUAL
256
B.4.1 U SE TIP TO T EST D IALING
To verify modem dialing, use the tip modemX command (where X is the appropriate modem number) to
connect the console terminal or telnet session directly to the modem.
Any dialer on the modem must first be killed. At the prompt, enter:
dialup modemX inactive
tip modemX
(where X is the appropriate modem number 0, 1, 2, 3, or 4)
Then enter:
AT
and expect to see in response:
OK
Enter:
ATDT 1-xxx-yyy-zzzz
where xxx-yyy-zzzz above is the correct dialing sequence for the number being tested. The modem dials
the remote Router number and responds with CONNECT 38400, followed by a sequence similar to “{.{a{”
indicating the other end is trying to start the PPP connect control protocol.
Now set the modem back to command mode by entering:
+++
Wait a few seconds. The response is
OK
indicating that the modem is now in command mode. Use ATH to terminate the
connection. If this works, exit tip by pressing ESC, and restart the dialer using the dialup command.
B.4.2 S AMPLE R EMOTE L OGIN D IALER S CRIPT
The following is an example of how the Router can be configured to connect to a Livingston PortMaster:
control down
wait 100
control up
speed 38400
send “AT&FS0=1&C1&D2&Q5&W\r” 100
wait 3000 “OK”
send “ATDT 1-555-426-1888\r”
wait 45000 “CONNECT 38400”
send “\r\r\r” 100
wait 45000 “login:”
send “ppp\r”
wait 10000 “word:”
send “ppp\r”
status up
