Burnham V9A - Manual (Page 55)

55
OIL BURNERS
Table VIII: Carlin Burner Specifications
Boiler
Model
Burner
Input
(GPH)
Burner
Mfr.
Burner
Model
Air Tube
Comb.
Burner Settings
Pump Pressure
(PSI) Nozzle
Make
Nozzle Data
Head
Air
Band
Air Damper
Low High
Low
Fire
High
Fire
V903A 3.1 Carlin 301CRD 8” - Style ‘B’ 1/4” 60% N/A N/A --- 150 Delavan 2.50 x 80° - B
V904A 4.2 Carlin 301CRD 8” - Style ‘B’ 1/2” 100% N/A N/A --- 150 Hago 3.50 x 80° - SS
V905A 5.6 Carlin 301CRD 8” - Style ‘C’ 34” 100% N/A N/A --- 150 Hago 4.50 x 80° - SS
V906A 7.0 Carlin 702CRD 10” Std. 7/32” N/A 1/2” Open 100 300 Hago 4.00 x 60° - P
V907A 8.3 Carlin 702CRD 10” Std. 1/2” N/A 1/2” Open 100 300 Hago 5.00 x 60° - P
V908A 9.6 Carlin 702CRD 10” Std. 3/4” N/A 1/2” Open 100 300 Hago 5.50 x 60° - P
V909A 11.6 Carlin 801CRD 10” Std. 1/4” N/A 1/4” Open 150 150 Hago
(L) 5.50 x 45° - H
(H) 4.00 x 45° - H
V910A 13.2 Carlin 801CRD 10” Std. 9/16” N/A 1/4” Open 150 150 Hago
(L) 6.50 x 45° - H
(H) 4.50 x 45° - H
V911A 14.8 Carlin 801CRD 10” Std. 3/4” N/A 1/2” Open 150 150 Hago
(L) 6.00 x 45° - H
(H) 6.00 x 45° - H
V912A 16.4 Carlin 801CRD 10” Std. 3/4” N/A 1/2” Open 150 150 Hago
(L) 7.00 x 45° - H
(H) 6.50 x 45° - H
SECTION VII - REPAIR PARTS
All V9A Series Repair Parts may be obtained through your local Burnham Wholesale distributor. Should
you require assistance in locating a Burnham Distributor in your area, or have questions regarding the
availability of Burnham products or repair parts, please contact Burnham Customer Service at 888-791-3790
or Fax (717) 293-5803.
