Messages, warnings and failures
1 - 1 5975977 RETRODATA 708 260597
8
MESSAGES, WARNINGS AND FAILURES
When selecting a new source, in-
formation about this source will be
displayed on the screen. Source
number, horizontal and vertical fre-
quencies of the displayed source.
SOURCE 01
Announcement of the selected
source.
INPUT 01
Fh= 15.6 kHz
Fv= 050 Hz
enter
password
x x x x
Message to enter your password.
Password contains 4 digits.
text on
text off
These messages will be displayed
on the screen when pushing the
TEXT key.
Text ON : the 'bar scale indication'
will be enabled during the change of
an analog control in the
'operational
mode' + all warnings and failures
will be displayed.
Text OFF : the 'bar scale indication'
will be disabled during the change
of an analog control in the
'opera-
tional mode' + all warnings and
failures will not be displayed.
PROJECTOR
ADDRESS :
003
Indication of the projector address
when activating the
'ADDRESS'
button on the RCU with a pencil or
other small object.
WARNING :
input not
available
When using the projector with the
RCVDS, this warning will be dis-
played when selecting an input slot
of an RCVDS where the input board
is missing.
WARNING :
source not
available
The input is a valid input but the
source is not connected to the
input terminals or the input source
is switched off.
WARNING :
invalid
key entry
When a wrong key is pressed on
the RCU.
WARNING :
end of ad-
just range
End of adjustment range.
WARNING :
input no
longer
available
Message will be displayed when
the input source is no longer avail-
able. The following message then
appears:
'check input signal or se-
lect new source' .
WARNING :
input se-
lector not
available
It warns you to check the power
connection or the power status of
the RCVDS.
Next message will appear
immediatly on the screen :
'go to
stand-by' .
WARNING :
invalid
frequency
input
The entered frequency or applied
frequency of the source is out of the
projector's range.
table is
deleted
Message to inform that selected
table is deleted. This message will
be followed by
'confirm message' ,
on which the user has to answer.
FAILURE
I2C error
addr. : 7FH3
Hardware failure. Call a qualified
service technician for repair.
FAILURE
short
circuit on
I2C bus
Hardware failure. Call a qualified
service technician for repair.
WARNING :
invalid
code entry
Message when the entered pass-
word is wrong.
