Service Mode
7 - 8
5975977 BARCODATA 708 280597
R & B convergence mid
Item is password protected.
Highlight
'R & B convergence mid'
with the control disk and press
ENTER
to set all convergence settings to their midposition. A
confirmation screen will be displayed first.
Select with or
then
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
R & B CONVERGENCE MID
Convergence settings
in current block
will be overwritten !
ENTER
sets the convergence settings to their midposition.
EXIT
cancels the procedure to set the convergence settings to their
midposition.
Undo R & B convergence mid
When "R & B convergence mid" is selected, all convergence settings
are set to their midposition. To cancel this action, select 'Undo R &
B convergence mid' by pushing the control disk up or down and press
ENTER. 'Undo R & B convergence mid' is displayed in the Memory
management menu in stead off 'R & B convergence mid' when this
latter is pressed.
An undo is possible as long as the projector is playing on the same
source (= same adjustment block) even when some adjustments are
already readjusted. When undo is presssed all settings are reset to
the previous settings.
Select with or
then
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
UNDO R & B CONVERGENCE MID
GR CONVERGENCE MID
Green convergence mid
Only available when the projector is equipped with green conver-
gence adjustmentes.
Highlight 'Gr convergence mid' by pushing the control disk up or
down and press
ENTER
to switch off the green convergence.
Select with or
then
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
Undo green convergence mid
Only available when the projector is equipped with green conver-
gence adjustmentes.
The item 'Undo green convergence mid' will automatically be dis-
played when the green convergence is switched to midposition.
Press
ENTER
to switch on the green convergence.
Select with or
then
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
UNDO GR CONVERGENCE MID
