Service Mode
7 - 6 5975977 BARCODATA 708 280597
Copy a block
The copy a block function copies the settings of a selected block into
the active block.
Highlight
copy a block with the control disk and press ENTER .
ENTER will select the highlighted item.
EXIT returns to the Path Selection main menu.
ADJUST returns to the Operational mode.
To copy the settings of a closed block to the block you are working
on (active block), use the control disk to select a block.
All existing settings will be overwritten with the new settings.
Press ENTER to copy the selected block. A confirmation screen will
be displayed.
Select with or
then
to return.
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
Select with or
to copy
to return.
COPY MODE
Nr. Src Fh Fv inp conf
1 1 15.6 50 video FC
2 3 31.2 60 RGB3S RT
3 - 15.6 50 intern FC
4 2 31.5 50 RGB3S FC
5 - 33.7 60 intern FC
6
7
8
Active block nr. 1
COPY BLOCK
All settings
in current block
will be overwritten !
to confirm
to cancel
ENTER displays a confirmation screen.
EXIT returns to the Service Mode main menu.
If you are certain you wish to copy the contents of the selected block
into the active block, press
ENTER .
EXIT cancels the copy procedure and returns without copying the
block.
Deletion of blocks
This item is password protected.
The delete function is used to clear all data (settings) from an
adjustment block.
A delete can be given :
- block by block
or
- for all blocks.
Deleting block by block
The ' delete a block' function deletes the settings of a selected block.
Highlight 'Delete a block' with the control disk and press ENTER .
Select with or
then
to return.
MEMORY MANAGEMENT
COPY A BLOCK
DELETE A BLOCK
DELETE ALL BLOCKS
ALL SETTINGS TO MIDPOS
R & B CONVERGENCE MID
GR CONVERGENCE MID
Select with or
then
to return.
Select with or
to copy
to return.
DELETE MODE
Nr. Src Fh Fv inp conf
1 1 15.6 50 video FC
2 3 31.2 60 RGB3S RT
3 - 15.6 50 intern FC
4 2 31.5 50 RGB3S FC
5 - 33.7 60 intern FC
6
7
8
Active block nr. 1
DELETE BLOCK
The selected block
will be deleted !
to confirm
to cancel
ENTER will select the pointed item.
EXIT returns to the Path Selection main menu.
ADJUST returns to the Operational mode.
Push the control disk up or down to select the desired adjustment
block. Press
ENTER to delete the selected adjustment block. A
confirmation menu will be displayed.
ENTER displays the confirmation menu.
EXIT returns to the Service Mode main menu.
ENTER will delete the selected block.
EXIT cancels the deletion procedure and returns to the Service mode
main menu.
