Service Mode
7 - 9
5975977 BARCODATA 708 260597
Common Settings
Highlight
'Common settings'
by pushing the control disk up or down
and press
ENTER
to display the common settings menu.
Within the common settings menu, the following items can be set up
or executed :
- G2 adjustment
- CRT run in cycle
- Projector warm up
Select with or
then
SERVICE MODE
PROJECTOR SET-UP
MEMORY MANAGEMENT
COMMON SETTINGS
I2C DIAGNOSTICS
Select with or
then
COMMON SETTINGS
G2 ADJUSTMENT
CRT RUN IN CYCLE
PROJECTOR WARM UP
G2 Adjustment
Item is password protected.
Highlight '
G2 adjust
' with the control disk and press
ENTER
to
continue.
A safety notice will be displayed on the screen as it is necessary to
open the top cover to adjust the G2.
Select with or
then
COMMON SETTINGS
G2 ADJUSTMENT
CRT RUN IN CYCLE
PROJECTOR WARM UP
CRT DRIVE MODE
SAFETY
NOTICE
RISK OF ELECTRICAL SHOCK
G2 ADJUSTMENT SHOULD BE
PERFORMED
BY BARCO PERSONNEL,
OR BARCO AUTHORIZED
DEALERS.
IF QUALIFIED, PRESS
IF NOT,
ENTER
selects the G2 adjustment.
EXIT
returns to the Common settings menu.
ADJUST
returns to the Operational mode.
'G2 adjustment should be performed by BARCO personnel, or
BARCO authorized dealers'.
If you are qualified, press
ENTER to continue. If not qualified, press
EXIT to return to the Common settings menu. Further description of
the G2 adjustment is given in the Installation manual.
CRT run in cycle
The CRT run in cycle option can only be activated when memory
blocks on an internal # pattern are available. When one or more such
blocks are available, a flashing white image (5sec on, 5 sec off) is
generated and that for 5 min on the first internal block. In the next 5
min, a second internal block will be used to generate the flashing
white image. The image will also be shifted in a vertical way to
prevent a CRT burn in. To quit the CRT run in cycle option, press
EXIT.
Highlight
'CRT run in cycle'
with the control disk and press
ENTER
to
start.
ENTER
selects the CRT run in cycle option.
EXIT
returns to the Path Selection main menu.
Select with or
then
COMMON SETTINGS
G2 ADJUSTMENT
CRT RUN IN CYCLE
PROJECTOR WARM UP
CRT DRIVE MODE
